Shim Sheets

Shim sheets are precision-engineered materials used for alignment, spacing, and support in industrial applications. Available in stainless steel, brass, copper, aluminum, and steel, they offer durability, accuracy, and customization for industries such as manufacturing, automotive, aerospace, HVAC, and machinery maintenance. Choosing the right shim material ensures optimal performance, reliability, and long-term equipment efficiency.

Thicknesses

0.02 – 6.00 MM

Tolerances

0.03 - 0.05MM

Min. Order

20 PCS / SIZE

ISO 9001: 2015 CERTIFIED

EXPORT TO 30+ COUNTRIES

DIMENSIONS & ORDERING

Models, Sizes & Specifications

8 standard models covering dimensions from 40mm up to 300mm. Custom sizes available on request.

Available Materials

Shim Sheets Metal

Pack Configuration

Tab-type shims: 8 dimensions × 10 thicknesses
SE single-slot: 5 dimensions × 10 thicknesses
Pack size: 10 pieces per thickness

Standard	SS 304
WERKSTOFF NR.	1.4301
UNS	S30400
JIS	SUS 304
BS	304S31
GOST	08Х18Н10
AFNOR	Z7CN18-09
EN	X5CrNi18-10

Model	Size	Minimum Quantity
SEP 1	40 X 40 X 12mm	20 Nos.
SEP 2	50 X 50 X 15mm	20 Nos.
SEP 3	75 X 75 X 20mm	20 Nos.
SEP 4	100 X 100 X 27mm	20 Nos.
SEP 5	130 X 130 X 30mm	20 Nos.
SEP 6	175 X 150 X 33mm	20 Nos.
SEP 7	250 X 200 X 36mm	20 Nos.
SEP 8	300 X 250 X 40mm	20 Nos.

Element	SS 304
Density	8.0 g/cm³
Melting Point	1400 °C (2550 °F)
Tensile Strength	Psi – 75000, MPa – 515
Yield Strength (0.2% Offset)	Psi – 30000, MPa – 205
Elongation	35%

Where Shims Sheet Are Used

Shims Sheet are used wherever fast, precise alignment is critical — across all major industrial sectors.

Oil & Gas

Aerospace

Automotive

Ship Building

Motor & Pump Alignment

Heavy Manufacturing

Power & Energy

Construction & Structural

Coupling Alignment

Applications, Specifications & Properties

Applications of Stainless Steel 304 Metal Shim Sheets

• Construction of buildings, bridges, and structures
• Food processing and storage containers in the food and beverage industry
• Precise thickness adjustments in machinery and equipment
• Insulation and soundproofing in various applications

Specifications of Stainless Steel 304 Metal Shim Sheets

Standard: ASTM / ASME A240 / SA240
Width: 14" (355 MM) to 24" (610 MM)
Thickness: Ranging from 0.05 MM to 0.40 MM
Forms: Decorative Round Hole, Dimpled, Square Holes, Gold Mirror Round Hole, Round Punch, Etched, Colored Shim Sheets
Finish: 2B, BA
Hardness: Available in Soft, Hard, Half Hard, Quarter Hard, Spring Hard, and more

Understanding Shim Sheets

Shim sheets are thin, flat products used in industrial and mechanical applications to fill gaps, align components, and adjust clearances. They are available in various sizes and materials to meet the specific requirements of construction, manufacturing, and machinery applications.

Properties of SS 304 Shim Plates

Shim plates manufactured from 304-grade stainless steel are widely used because of their excellent strength, corrosion resistance, durability, and temperature resistance. They perform reliably in demanding environments, including exposure to moisture and corrosive conditions, making them ideal for construction, automotive, and industrial applications.

Standard Shim Sizes in mm for SS 304 Grade

Standard shim sizes in mm for Stainless Steel 304 vary depending on the intended application. Shim sets include thicknesses ranging from 0.05 mm to 5 mm and can be combined to achieve the required finished thickness. Standard bar stock is also available in metric sizes from 1 mm to 6 mm thick and 12 mm to 100 mm wide.

Quality Assurance

Stainless Steel 304 Shim Sheets undergo rigorous quality testing, including PMI tests, IGC tests, mechanical tests, chemical tests, flattening tests, and flaring tests. These procedures ensure high quality, consistency, and reliability for industrial applications.

Sachin Shims: Your Trusted Supplier

Sachin Shims is a leading supplier and stockist of premium-quality SS Shim Sheets. These sheets are suitable for ceilings, curtain walls, buildings, food packaging, air conditioning systems, air filters, and many other industrial applications. We provide expert guidance and dependable products tailored to your requirements.
