Conical Washers
Conical washers are cone-shaped washers designed to provide a snug fit and even load distribution. They improve stability and prevent loosening in high-vibration applications, making them ideal for mechanical, engineering, and automotive use.
ISO 9001: 2015 CERTIFIED
EXPORT TO 30+ COUNTRIES
Key Features
Designed to improve load distribution, alignment, and fastening performance across a wide range of applications.
They have a cone-like shape with a tapering edge, which helps distribute pressure more evenly.
The conical design helps to spread the load over a larger area, reducing stress on specific points.
The conical shape can assist in aligning parts more precisely, ensuring a tighter and more stable connection.
The larger surface area in contact with the fastener helps to improve grip and stability.
Available in various sizes and angles, making them suitable for different applications and load requirements.
Available in a variety of metal and plastic materials, these washers are designed to meet diverse application and strength requirements.
Models, Sizes & Specifications
Sealing washers are available in sizes from M3 to M100+. Thickness ranges from 0.5 mm to 5 mm as per requirement.
Available Materials
Pack Configuration
- Tab-type shims: 8 dimensions × 10 thicknesses
- SE single-slot: 5 dimensions × 10 thicknesses
- Pack size: 10 pieces per thickness
Conical Washer Specifications, Sizes And Schedules
| Bolt Size | Top Outside Diameter (A) | Bottom Outside Diameter (B) | Thickness (T) | Weight (grams) |
|---|---|---|---|---|
| 1/2 | 1-1/4 | 2-1/4 | 1/8 | 45 |
| 5/8 | 1-1/2 | 2-1/2 | 5/32 | 60 |
| 3/4 | 1-3/4 | 2-3/4 | 3/16 | 80 |
| 7/8 | 2 | 3 | 7/32 | 105 |
| 1 | 2-1/4 | 3-1/4 | 1/4 | 135 |
| 1-1/8 | 2-1/2 | 3-1/2 | 5/16 | 200 |
| 1-1/4 | 2-3/4 | 4 | 3/8 | 240 |
| 1-1/2 | 3 | 4-1/2 | 7/16 | 350 |
